IKELITE UNDERWATER TTL HOUSING 200DLM/A FOR CANON EOS M50, KISS M

With IKELITE UNDERWATER TTL HOUSING 200DLM/A FOR CANON EOS M50, KISS M, you can capture brilliant images and video at depths as great as 200'. An Ikelite sync bulkhead and built-in TTL circuitry enable the connection of optional external strobes. Ikelite DS flash units can be used in TTL or manual exposure mode, while third-party strobes will work in manual mode.

SPECIFICATIONS:

• 200 ft (60m) depth rating
• DLM/A port mount
• Controls for all important camera functions; control is not provided for the Wi-fi function
• Ikelite flash bulkhead connector with built-in TTL circuitry
• Two 1/4-20 threaded tray mounts with 3" (76mm) spacing
• Slightly negative buoyancy in fresh water
• Actual buoyancy varies depending on the choice of lens and port
• 7 lb (1225 g)
• 5 x 5.8 x 5.4" (191 x 147 x 137 mm)
• ABS-PC, acrylic, and acetyl construction

Construction Details

• Made by hand in the USA from corrosion-resistant polycarbonate and ABS plastic blend
• Stainless-steel locking latches
• Open-groove rear O-ring is easy to maintain and offers visual confirmation of seal
• 1/2"-20 threaded accessory port for optional Vacuum Kit
• The camera is installed and removed through the front of the housing
• The mounting plate allows for secure camera placement without hindering access to the battery compartment or memory card slot
• The mounting plate has a 1/4"-20 threaded hole for connection to a tripod

Controls and Handling

• Large, ergonomic controls including push-buttons, dials, and levers
• Afford access to all camera functions except Wi-Fi
• Soft-touch knobs are easy to grip with or without gloves
• Curved shutter lever hugs side of the housing
• Optional Shutter Trigger Extension can be added on to allow for easy shutter activation when using a grip
• Laser-engraved control symbols on the back of the housing won't come off or fade with time
• Super eye Viewfinder gives you a clear view through the camera's optical finder when you're wearing a dive mask
• The camera's LCD screen can be tilted prior to installation for easier viewing
• Two 1/4"-20 threaded mounts on the bottom of the housing allow for connection to the optional tray

Lens Ports

• Ships without a required lens port
• Accepts various interchangeable dome and flat ports for a broad array of lenses
• Simply press the port on and tighten three thumbscrews

Strobe Connection and Operation

• The circuit is powered by a strobe
• Exposure compensation in TTL mode is supported using the camera's built-in control
• Ikelite DS strobe are operable in TTL or manual mode
• Third-party strobes operable in manual mode only
• Sync cord is sold separately
