IKELITE UNDERWATER HOUSING 200DL FOR NIKON D7500

Capture brilliant images of the aquatic world with your IKELITE UNDERWATER HOUSING 200DL FOR NIKON D7500, which has a depth rating of 200'. An Ikelite bulkhead with a manual hot shoe connection enables reliable electrical triggering of optional external strobes via sync cords. The use of an optional TTL hot shoe and converter will allow for TTL operation with compatible Ikelite DS strobes; non-Ikelite strobes will still work in manual mode only.

Construction Details

• Depth rating of 200'
• Housing is made by hand in the USA from a corrosion-resistant polycarbonate and ABS plastic blend
• White on the front, top, sides, and bottom to reflect sunlight and keep the camera cool when shooting on or above the water's surface
• Clear in the back to allow you to monitor the O-ring seal and maintain your view of the camera's rear controls
• Housing alone has nearly neutral buoyancy in freshwater, though your choice of lens and port may change the overall buoyancy of the system
• Open-groove design suspends the rear O-ring in the natural position, making maintenance easier and preventing accidental twisting or stretching
• Front-loading mounting plate enables quick camera installation and allows access to the battery compartment and memory card slot
• The mounting plate has a 1/4"-20 threaded hole on the bottom for connection to an optional tripod

Strobe Connection and Operation

• Use of an optional external strobe is highly recommended for color correction and adequate brightness, and is basically essential once you descend to depths greater than 15-20'
• Strobe restores hues that are absorbed by the water, so your images are vibrant and accurate
• To ensure that your images are as clear and colorful as possible, try to stay no more than 3-4' away from your subjects
• Ikelite ICS-5 bulkhead with manual hot shoe connection enables reliable electrical triggering of strobes
• Optional NT2 Nikon TTL hot shoe and 4301.3 converters will enable TTL operation with compatible Ikelite DS strobes, which use the #4103.51 Single and #4103.52 Dual Sync Cords
• Non-Ikelite strobes, such as those from Sea & Sea, INON, and Retra, will still work in manual mode only and can be connected via #4118.1 Single and #4118.2 Dual Sync Cords
• Older non-digital strobes can be used in manual mode via #4103.51 Single and #4103.52 Dual Cords
• Housing ships without a required sync cord for a strobe
• Bulkhead has been moved to the top of the enclosure to keep the cord out of your way and reduce strain on the ends
• Ikelite's #4403 Optical Slave Converter and Aquatica's Water Wizard system are available options that will let you trigger wireless slave strobes
• Exposure compensation is available via the camera's controls

Controls and Handling

• Sensitive shutter and AE-L/AF-L levers are curved and extendable to increase comfort when using the optional right-hand grip
• Upgraded soft-touch knobs, including the zoom knob on the side, allow for a better, more comfortable grip with or without gloves
• Push-buttons have been modified to reduce weight and salt buildup
• Ergonomic, mechanical push-buttons, knobs, and levers afford access to all camera functions except for the following: release mode dial, release mode dial lock release, diopter adjustment control, focus mode selector, focus selector lock, bracketing button, and Fn1 and Fn2 buttons
• Control placement is as close as possible to the layout of functions on the camera, allowing your muscle memory to guide you--so you don't have to learn another set of controls
• Symbols for the controls are etched into the back of the housing with lasers, so they won't fade or fall off with time
• Supereye Viewfinder enhances your view through the camera's OVF when you're wearing a mask
• You can remove the Supereye quickly if you'd like to attach the optional Straight or 45° Magnified Viewfinder instead
• A hard-anodized aluminum tray with a left-hand quick-release grip improves balance and handling while offering an attachment point for an optional lighting arm
• 1/4"-20 mounts and other mounting points on the tray enable a connection to a tripod and the addition of accessories
• The optional right-hand grip can be added easily
• The tray is more than 3/4 lb lighter than Ikelite's previous model
• Housing is a 1/2 lb lighter than its FL-mount counterpart
• Another 1/4"-20 threaded mount is located front and center on the housing above the port mount, allowing for the attachment of focus light, GoPro action camera, or another lightweight piece of equipment
• Optional Cable Grip or Aluminum Top Handle can be added for easier carrying if you're using 2 strobes

Lens Ports

• Ships without a required lens port
• Accepts all Ikelite Dry Lock (DL) dome and flat ports, enabling you to use a wide variety of lenses with the appropriate zoom and focus gears
• For complete compatibility information, see the port chart linked above
• DL port system accommodates lenses with large diameters
• Provides added security against leaks at the surface, thanks in large part to the included vacuum valve that helps you check watertight integrity before the dive
• Removal of excess air to create a vacuum requires #47011 Pump with Gauge
• DL mount can be removed and replaced by the older FL (Four Lock) port locks, though this change would be irreversible unless you sent the housing back to Ikelite to have the DL mount installed again
