Insta360 ACE PRO DIVE CASE

Take your Ace Pro action camera underwater on your next scuba diving excursion using this Insta360 ACE PRO DIVE CASE. The case can be submerged to depths up to 197' underwater and features a locking-buckle design for additional security.

 A 2-prong mount on the base allows you to attach your camera to a selfie stick. Your images remain high-quality thanks to the high-transparency optical glass lens. Included anti-fog inserts further protect visibility while anti-slip rings reinforce a tripod connection.

FEATURES:

·         Waterproof to 197ft (60m).

·         Glass lens for better image quality.

·         Sliding buckle design to keep the camera safe and secure.

DIVE CASE

Capture stunning underwater shots.

DIVE A LITTLE DEEPER

The purpose-built sealed structure lets you shoot as deep as 197ft (60m).

CLEAR OPTICAL GLASS LENS

Higher transparency than a plastic lens, guaranteeing clear and detailed shots. The hydrophobic and oil-resistant coat reduces light reflections and warping.

SAFE AND SOUND

Easy-to-use waterproof dive case with a sturdy buckle lock design to secure your camera.

PERFORMANCE GUARANTEED

Designed and tested to protect Ace Pro and enhance underwater image quality.

IN THE BOX:

·         1 X Dive Case

·         1 X Carry Pouch

·         8 X Anti-Fog Inserts

·         4 X Anti-Slip Ring

SPECIFICATIONS:

·         Maximun Depth:      60m (197ft)

·         Weight:        118g (4.2oz)

HOW TO USE:

·         Open the Case

o    Push the Lock lever to the right (1) and push the buckle down as shown below (2). Unlatch the buckle from the hook (3) and open the dive case (4).

·         Attach the Anti-Fog Inserts

o    Insert the Anti-Fog inserts as shown below.

Note: When using third-party anti-fog inserts, ensure that the size of Anti-Fog Insert 1 is within 20x15x1.2mm and Anti-Fog Insert 2 is within 40x15x1.2mm. If the inserts are too large, they may cause water leakage and damage the camera.

·         Insert the Camera

o    Be sure to insert in the camera in the correct direction so the button are properly aligned.

Note:

§  When using the camera in water, please lock the touchscreen to avoid accidental presses.

§  When inserting the camera, take care not to scratch the lens.

·         Close the Case

o    Latch the buckle onto the case’s hook and firmly push down until it clicks.

Note:

§  Ensure the Dive Case is firmly closed. Be sure that the parts of the Dive Case in contact with its rubber seal are free of dirt or dust.

§  For the best results, keep the Dive Case clean.

·         Attach the Anti-slip Ring

o    When connecting the Dive Case to other accessories, such as the Floating Hand Grip, stick an Anti-slip Ring to the screw points to reduce the risk of vibrations loosening or damaging your case.

NOTES:

1.    Before using the Dive Case, please update your camera's firmware to the latest version.

2.    Improper maintenance may affect product performance. Each time before placing the camera in the Dive Case, it's suggested to latch the Dive Case (without the camera inserted) and immerse it in water to check for leaks.

3.    Before sealing the Dive Case, be sure that the parts of the Dive Case in contact with its rubber seal are free of any foreign objects (dirt, dust, sand, etc.). Make sure the rubber seal is correctly aligned and is not broken or twisted.

4.    The Dive Case is not shock-resistant. Applying strong vibrations, shocks, or pressure to the product may result in damage, failure or reduced waterproofing performance. The recommended maximum dive height is 2 meters (6.56ft) above water level when diving into water. The Dive Case protects the camera when dropped on solid surfaces from a maximum dropping distance of 1 meter (3.28ft).

5.    Do not open the Dive Case while it is wet.

6.    After using the product in seawater, remove the camera and ensure the Dive Case is firmly closed. Soak the Dive Case in freshwater for 5-10 minutes, then gently rinse it under the tap

7.    Do not store the Dive Case in a hot and humid environment like a hot car. Do not wash the Dive Case with soap, neutral detergent, organic solvents or alcohol cleaning products, as this may affect the waterproofing performance.
